MIDI Control Change Associations
Global & Switching
Parameter CC# Value
PRESET ON/OFF 12 OFF = 0, ON = 127
TUNER 9 Toggle
TAP TEMPO 10 Toggle
BPM 88 000 - 127
PRESET DOWN 86 Toggle
PRESET UP 87 Toggle
Each parameter is assigned to a control change as shown in the following tables.
When a parameter range is not linear its values are equally divided among the 128 steps
of a Control Change value.
Main Amp Parameters
Parameter CC# Value
GAIN 102 000 - 127
BASS 23 000 - 127
MID 25 000 - 127
TREBLE 28 000 - 127
VOLUME (MODEL) 103 000 - 127
PRESENCE 106 000 – 127
DEPTH 107 000 – 127
MIX (MODEL) 104 000 - 127
Noise Gate
Parameter CC# Value
GATE/ POWER 14 000: OFF, 127: ON
GATE/ THRESHOLD 15 000 – 127
GATE/ RELEASE 16 000 – 127
GATE/ DEPTH 17 000 – 127
GATE/ POSITION 13 000: FIRST, 127: POST AMP
Compressor
Parameter CC# Value
COMP/ POWER 18 000: OFF, 127: ON
COMP/ THRESHOLD 19 000 – 127
COMP/ GAIN 20 000 – 127
COMP/ ATTACK 21 000 – 127
COMP/ POSITION 22 000 – 127
EQ
Parameter CC# Value
EQ/ BASS FREQ 24 000 – 127
EQ/ MID Q 26 000 – 127
EQ/ MID FREQ 27 000 – 127
EQ/ TREBLE FREQ 29 000 – 127
EQ/ POSITION 30 000 – 127
Reverb
Parameter CC# Value
REVERB/ POWER 75 000: OFF, 127: ON
REVERB/ TYPE 85 000: SPRING 1
001: SPRING 2
002: SPRING 3
003: SPRING 4
004: ROOM
005: PLATE
REVERB/ POSITION 84 000: POST AMP, 127: LAST
Reverb/ Spring 1
Parameter CC# Value
SPRING 1/ TIME 59 000 - 127
SPRING 1/ PRE.DELAY 60 000 – 127
SPRING 1/ COLOR 61 000 – 127
SPRING 1/ MIX 62 000 - 127
Reverb/ Spring 2
Parameter CC# Value
SPRING 2/ TIME 63 000 - 127
SPRING 2/ PRE.DELAY 64 000 – 127
SPRING 2/ COLOR 65 000 – 127
SPRING 2/ MIX 66 000 - 127
Reverb/ Spring 3
Parameter CC# Value
SPRING 3/ TIME 67 000 - 127
SPRING 3/ PRE.DELAY 68 000 - 127
SPRING 3/ COLOR 69 000 - 127
SPRING 3/ MIX 70 000 - 127
Reverb/ Spring 4
Parameter CC# Value
SPRING 4/ TIME 80 000 - 127
SPRING 4/ PRE.DELAY 81 000 - 127
SPRING 4/ COLOR 82 000 - 127
SPRING 4/ MIX 83 000 - 127
Reverb/ Room
Parameter CC# Value
ROOM/ TIME 71 000 - 127
ROOM/ PRE.DELAY 72 000 - 127
ROOM/ COLOR 73 000 - 127
ROOM/ MIX 74 000 - 127
Reverb/ Plate
Parameter CC# Value
PLATE/ TIME 76 000 - 127
PLATE/ PRE.DELAY 77 000 - 127
PLATE/ COLOR 78 000 - 127
PLATE/ MIX 79 000 - 127
Delay
Parameter CC# Value
DELAY/ POWER 2 000: OFF, 127: ON
DELAY/ TYPE 3 000: DIGITAL, 001: TAPE
DELAY/ POSITION 1 000: PRE AMP, 127: POST AMP
Delay/ Digital Delay
Parameter CC# Value
DELAY/ DIGITAL/SYNC 4 000: OFF, 127: ON
DELAY/ DIGITAL/TIME 5 000 - 127
DELAY/DIGITAL/FDBCK 6 000 – 127
DELAY/ DIGITAL/MODE 7 000: NORMAL, 001: PING.PONG
DELAY/ DIGITAL/ MIX 8 000 – 127
Delay/ Tape Delay
Parameter CC# Value
DELAY/ TAPE/ SYNC 91 000: OFF, 127: ON
DELAY/ TAPE/ TIME 92 000 – 127
DELAY/ TAPE /FDBACK 93 000 – 127
DELAY/ TAPE / MODE 94 000: NORMAL, 001: PING.PONG
DELAY/ TAPE / MIX 95 000 - 127
Modulation
Parameter CC# Value
MOD/ POWER 32 000: OFF, 127: ON
MOD/ TYPE 33 000: CHORUS
001: TREMOLO
002: PHASER
003: FLANGER
004: ROTARY
MOD/ POSITION 31 000: PRE AMP, 127: POST AMP
Modulation/ Chorus
Parameter CC# Value
MOD/ CHORUS/ SYNC 34 000: OFF, 127: ON
MOD/ CHORUS/ RATE 35 000 - 127
MOD/ CHORUS/ DEPTH 36 000 - 127
MOD/ CHORUS/ LEVEL 37 000 - 127
Modulation/ Tremolo
Parameter CC# Value
MOD/ TREMOLO/ SYNC 38 000: OFF, 127: ON
MOD/ TREMOLO/ RATE 39 000 – 127
MOD/ TREMOLO/ SHAPE 40 000 – 127
MOD/ TREMOLO/SPREAD 41 000 – 127
MOD/ TREMOLO/ LEVEL 42 000 – 127
Modulation/ Phaser
Parameter CC# Value
MOD/ PHASER/ SYNC 43 000: OFF, 127: ON
MOD/ PHASER/ RATE 44 000 – 127
MOD/ PHASER/ DEPTH 45 000 – 127
MOD/ PHASER/ LEVEL 46 000 - 127
Modulation/ Flanger
Parameter CC# Value
MOD/ FLANGER/ SYNC 47 000: OFF, 127: ON
MOD/ FLANGER/ RATE 48 000 – 127
MOD/ FLANGER/ DEPTH 49 000 – 127
MOD/ FLANGER/FDBACK 50 000 – 127
MOD/ FLANGER/ LEVEL 51 000 – 127
Modulation/ Rotary
Parameter CC# Value
MOD/ ROTARY/ SYNC 52 000: OFF, 127: ON
MOD/ ROTARY/ SPEED 53 000 – 127
MOD/ ROTARY/ RADIUS 54 000 – 127
MOD/ ROTARY/ SPREAD 55 000 – 127
MOD/ ROTARY/ LEVEL 56 000 – 127
