CC# Controller Map
The GSP1101 uses a Global Controller map for routing incoming MIDI CC and Expression Pedal
messages to Expression Links within in a preset. There are 16 Global Controllers, each of which
can be assigned to a different MIDI CC or the Expression Pedal. Once these Global Controllers are
set up, you can then link up to eight Controllers to individual parameters in presets for customized
functionality. From the factory, the Global Controllers have been assigned to some MIDI CCs
already, but feel free to make changes to these assignments for your own needs.

To set up the Global Controller mapping
1. From the Preset screen, press the Edit/Select knob.

2. Turn the Edit/Select knob until the MIDI menu is selected and press the knob.

3. Turn the Edit/Select knob until CC/Controller Map is selected and press the Edit/Select
   knob. This enters the MIDI CC/Controller mapping menu.

4. Turn the Edit/Select knob to select one of the 16 Global Controllers you want to map a MIDI
   CC to and press the Edit/Select knob.

5. Turn the Edit/Select knob to select the MIDI CC number you want this controller to respond
   to (0-127).

6. Press the Back button to return to the previous menu and repeat steps 3 and 4 for other
   global controllers.

7. Press and hold the Back button to return to the Preset screen.
